Grade M10: PCC (Plain Cement Concrete)
Leveling Course, Bedding For Footing, Concrete Roads, Etc.
Grade M15: PCC (Plain Cement Concrete)
Leveling Course, Bedding For Footing, Concrete Roads, Etc
Grade M20: RCC (Reinforced Cement Concrete)
Slabs, Beams, Columns, Footings, Etc. (For Mild Exposure)
Grade M25: RCC (Reinforced Cement Concrete)
Slabs, Beams, Columns, Footings, Etc.
Grade M30: RCC (Reinforced Cement Concrete)
Slabs, Beams, Columns, Footings, Etc.
Grade M35: RCC (Reinforced Cement Concrete)
Slabs, Beams, Columns, Footings, Etc.
Grade M40: RCC (Reinforced Cement Concrete)
Pre-stressed Concrete, Slabs, Beams, Columns, Footings, Etc.
Grade M45: RCC (Reinforced Cement Concrete)
Runways, Concrete Roads (Pqc), Prestressed Concrete Girders, Rcc Columns, Spans Prestressed Beams.
Quality Meets
Cutting Edge Technology!
Various Types of Quality Checks at our Laboratory
Cube Test
Sample cubes of concrete are taken from every site and cured for 28 days . The respective cubes are tested using compressive testing machine to find the strength of concrete on 7th and 28th days respectively. The testing can also be done in the presence of customer at our in house laboratory .
Slump Test
It measures the consistency of a concrete mix or its stiffness. A conical mould is filled with fresh concrete in 3 stages & rammed with a standard rod. The mould is lifted without disturbing the cone . The subsidence of the concrete from the height of the cone is measured to the nearest 5cm. The testing can also be done in the presence of customer at our in house laboratory . The tests is done in the presence of the customer at the delivery site Low slump test results lower workability .
Silt Content Test
Is to find the silt content of manufactured sand that is used as raw material for making concrete Silt is granular material of a size between sand and clay. Presence of silt in aggregates result in increased shrinkage or permeability, In addition to poor bonding .
Sieve Analysis
This test is carried to determine the particle size distribution in a sample of fine and coarse aggregates. Fineness modulus of the material is calculated,sand having F.M>3.2 is unsuitable.
Specific Gravity
To find the specific gravity of fine and course aggregates by pycnometer. It is considered to be a measure of strength or quality of material .It is also required for workability measurements.
Impact Test
Resistance of the aggregate to failure by impact is tested by the impacting testing machine. The ratio of fines(finer than 2.36mm) to the total weight of a sample is the Aggregate impact value. The Aggregate Impact value is kept as specified in IS 283:1970.
